Omega 2 EOperation
6.1 U nloading medium
1. Carry out the following procedure in the software:
– Click Media.
– Click Unload.
The Unload dialog window appears.
2. Remove medium.
3. Click OK.
6.2 L oading a roll media
A roll m edium can be loaded by one person.
Procedure
The roll medium is loaded in the following steps:
Create new media channel if necessary (→ Page 55 / Creating and
editing media channels).
Initiate loading process in the software.
Load new roll.
Insert medium.
Enter position of the medium.
6.2.1 Initiating loading procedure in the software
1. Click Media.
2. Select the desired media channel.
3. Click Load.
The Load/Unload Media dialog window appears.
4. Set the suction area (→ Page 34 / Setting suction area).
5. Click OK.
The Load dialog window appears.
6.2.2 Load new roll
A sliding clutch is located on the right side of the axis on the loading
side. Use only this axis, which is intended for the printer.
The integrated sliding clutch generates mechanical resistance against
the direction of roll rotation. This tensions the medium and ensures
that it is drawn in stra ight.
1. Slide the axis into the core of the new roll.
2004 – 2014 © Durst Pho totechn ik AG – www.durst-online.co m , Omega 2 , Issued 07/201 4 35 / 91
