Omega 2 C Description
During printing, the print carriage (2) passes over the medium. The print
heads on the print carriage print the medium with ink. The UV lamps in the
UV lamp head (1) dry the ink on the medium.
The sliding doors (6) are locked for the protection of the user during the
printing process.
The p rinter is operated at the external workstation.
Roll media
Roll media (10) are tensioned by a dancing roller on the unloading side and
wound up on the take-up roll (8).
Plate media
Plate media (5) are positioned on the loading aids (3) of the loading unit and
placed on the loading aids of the unloading side after printing. The loading
aids can be removed and stored in the loading unit so that roll media can be
printed.
1.1 Workstation
Task The printing process is controlled and monitored at the external workstation.
Function
The software used to control the printer is found on the workstation.
The images to be printed can be loaded via a network cable to the workstation
from the external CALDERA RIP station.
The operator carries out the following activities:
Preparation of the printer for loading the medium a
nd for maint enance
work
Basic printing settings
Modification of print parameters
Sorting of images in the print queue
Initiation of the printing process
1.2 Ink supply unit
Task
The ink supply unit provides the print heads with ink of different colors.
2004 – 2014 © Durst Pho totechn ik AG – www.durst-online.co m , Omega 2 , Issued 07/201 4 23 / 91
