Eaton easy800

5 Function blocks
5.4 BT, Data block Transformer
150 Control Relay easy800 11/11 MN04902001Z-EN www.eaton.com
Operating mode
The operating mode setting defines whether marker ranges are to be copied
or initialized.
The factory setting of this parameter is INI.
Inputs
I1 and I2: Function block inputs I1 and I2 are used to define the beginning of
the source and destination range.
The entry at function block input NO determines the number of elements to
be written.
You can assign the following operands to function block inputs I1 and I2 and
NO:
• Constant.
• Markers MD, MW, MB.
• Analog inputs IA01 to IA04:
• IA01: Terminal I7.
• IA02: Terminal I8.
• IA03: Terminal I11.
• IA04: Terminal I12.
• Analog output QA01.
• Output
…QV of a different function block.
Specifying the marker range
Marker ranges can be specified with or without an offset.
Marker range without offset
If MB, MW or MD markers are specified at both I1 and I2 the number of the
markers is the start of comparison range.
Marker range with offset
If you wish to work with an offset, specify one of the following variables at
function block input I1 or I2.
• Analog input IA..
• Analog output QA..
BT07
Function block: Data block transfer, number 07
INI
Operating mode: INI
+
Parameter set can be called via the PARAMETERS menu
>I1
Start of source range or initialization markers (MB,MW,MD)
>I2
Destination range start
>NO
Number of elements to be written in bytes per range, number: 1 - 383
Parameters
Function
INI Initialize marker ranges
CPY
Copy marker ranges
