Eaton easy800 User Manual

12 Appendix
12.6 Compatibility of SWD stations
Control Relay easy800 11/11 MN04902001Z-EN www.eaton.com 363
12.6 Compatibility of SWD stations
Table 26: List of types that are compatible with one another
Part no. Description Allowed
replacement type 1
Allowed
replacement type 2
RMQ function elements (front mount)
M22-SWD-K11 Function element, 2 pos. front M22-SWD-K22
M22-SWD-K22 Function element, 3 pos. front -
M22-SWD-LED-W Function element, LED W front M22-SWD-K11LED-W M22-SWD-K22LED-W
M22-SWD-K11LED-W Function element, 2 pos.,
LED-W, front
M22-SWD-K22LED-W
M22-SWD-K22LED-W Function element, 3 pos.,
LED-W, front
-
M22-SWD-LED-R Function element, LED-R front M22-SWD-K11LED-R M22-SWD-K22LED-R
M22-SWD-K11LED-R Function element, 2 pos., LED-R,
front
M22-SWD-K22LED-R
M22-SWD-K22LED-R Function element, 3 pos., LED-R,
front
-
M22-SWD-LED-G Function element, LED-G front M22-SWD-K11LED-G M22-SWD-K22LED-G
M22-SWD-K11LED-G Function element, 2 pos.,
LED-G, front
M22-SWD-K22LED-G
M22-SWD-K22LED-G Function element, 3 pos.,
LED-G, front
-
M22-SWD-LED-B Function element, LED-B front M22-SWD-K11LED-B M22-SWD-K22LED-B
M22-SWD-K11LED-B Function element, 2 pos., LED-B,
front
M22-SWD-K22LED-B
M22-SWD-K22LED-B Function element, 3 pos., LED-B,
front
-

Eaton easy800 Specifications

General

Supply voltage	24 VDC, 100-240 VAC
Programming Software	EASY-SOFT
Display	LCD
Protection class	IP20
Number of Digital Inputs	8
Communication Ports	RS-485
Operating temperature	-25°C to +55°C
