Eaton easy800

12 Appendix
12.3 Technical data
Control Relay easy800 11/11 MN04902001Z-EN www.eaton.com 359
12.3.7 NET network
1) Bus lengths above 40 m can only be achieved with cables with reinforced cross-section and connection adapter.
1 baud = 1 bit/s
Number of stations max. 8
max. bus lengths/at baud rate
1)
m/Kbaud
6/1000
25/500
40/250
125/125
300/50
700/20
1000/10
Potential isolation
To power supply (POW), inputs, outputs, easyLink, PC interface,
memory module, SWD, AUX
Yes
Bus termination (￫ accessories)
First and last station Yes
Plug connector (￫ accessories) poles
8
Type
RJ45
Cable cross-sections, with cable lengths and cable resistance/m
Cross-section up to 1000, < 16 mΩ/m mm
2
(AWG) 1.5 (16)
Cross-section up to 600, < 26 mΩ/m mm
2
(AWG)
0.75 to 0.8 (18)
Cross-section up to 600, < 26 mΩ/m mm
2
(AWG)
0.5 to 0.6 (20, 19)
Cross-section up to 400 m, < 40 mΩ/m mm
2
(AWG)
0.34 to 0.5 (22, 21, 20)
Cross-section up to 250 m, < 60 mΩ/m mm
2
(AWG)
0.25 to 0.34 (23, 22)
Cross-section up to 175 m, < 70 mΩ/m mm
2
(AWG)
0.13 (26)
Cross-section up to 40 m, < 140 mΩ/m mm
2
(AWG)
1.5 (16)
