Eaton easy800

12 Appendix
12.3 Technical data
360 Control Relay easy800 11/11 MN04902001Z-EN www.eaton.com
12.3.8 SmartWire-DT
SWD power supply
(generated from the POW supply voltage)
easy800-SWD
Rated operational voltage U
e
V
14.5 g 3 %
Current
1)
I
max
A
EASY802-DC-SWD: 0.4
EASY806-DC-SWD: 0.7
Short-circuit strength
yes
Potential isolation
from power supply, POW, inputs, outputs no
to easyNet
yes
to the PC interface (COM)
yes
SWD-line
Number of SWD stations max. 99
Maximum length of SWD line m
max. 600
Baud Rate kBd
125/250
Physics of the data cable
RS485
Address setting
Automatically via Configuration button
Status display
Multi-color SWD-LED: orange/green/red
Dual colored Config LED: green/red
Connections
Plug, 8-pole
Plug connectors
Blade terminal SWD4-8MF2
Bus termination
Integrated in the device
The end of the SWD line must be
terminated with: SWD-RC8-10
1) If SWD components with a higher total power consumption are connected, an EU5C-SWD-PF2 power feed
module must be used.
