5 Function blocks
5.17 HY - Year Time Switch
206 Control Relay easy800 11/11 MN04902001Z-EN www.eaton.com
The following nine entry rules are possible (XX = position used)
Rule 1
ON: Day
OFF: Day
Rule 2
ON: Month
OFF: Month
Rule 3
ON: Year
OFF: Year
Rule 4
ON: Day/month
OFF: Day/month
Rule 5
ON: Month/year
OFF: Month/year
Rule 6
ON: Day/month/year
OFF: Day/month/year
Rule 7
Two-channel
Channel A ON: Day/month
Channel B OFF: Day/month
Rule 8
Two-channel
Channel C ON: Day/Month/Year
Channel D OFF: Day/month/year
With this rule, the same year number must be entered in each channel in the
ON and OFF entry area.
Rule 9
Overlapping channels: The first ON date switches on and the first OFF date
switches off.
