Eaton easy800

5 Function blocks
5.23 NC, numerical converter
226 Control Relay easy800 11/11 MN04902001Z-EN www.eaton.com
BIN mode
The binary value present at input >I1 is converted to a BCD value and
supplied at the output QV>. The binary value is displayed as a decimal value.
Examples:
I1
(dec)
BIN BCD QV
(dec)
7 0000 0111 1001 7
11 0000 1011 0001 0001 17
19 0001 0011 0001 1001 25
13 0000 1101 0001 0011 19
9999999 0001 0001
0001 0110
0111 1111
0000 1001
1001 1001
1001 1001
1001 1001
161061273
-9099 10000 0000
0000 0000
0010 0011
1000 1011
1000 0000
0000 0000
1001 0000
1001 1001
-18585
￫
Bit 32 is the sign bit. Bit 32 = 1  Sign = Minus.
￫
Values greater than 9999999 are output as 161061273.
Values less than –9999999 are output as –161061273.
The working range of the function block has been exceeded.
Memory
32 + per 4 Byte/Constant at function block input
Cycle time [μs]
easy800 standard easy800-SWD
BCD
34 14
BIN
127 28
NC
