Eaton easy800

7 SmartWire-DT
7.4 Errors on the SWD line
Control Relay easy800 11/11 MN04902001Z-EN www.eaton.com 295
LEDs on the device
The SWD-LED indicates whether the actual configuration of the SWD line
matches the target configuration.
The Config LED shows the result of the configuration comparison between
the saved target configuration and the project configuration below.
The devices and station parameters are taken into account.
Table 20: LEDs of easy800-SWD
LEDs on the station
Table 21: LEDs on the relevant station
Further information is provided in the manual “SmartWire-DT - The System”
(MN05006002Z-EN).
LED
Status
POW Off no supply voltage at POW
green continuous light easy800-SWD in STOP mode
Green flashing easy800-SWD in RUN mode
SWD
Off no supply voltage at POW
no target configuration present
green continuous light Actual configuration = Target configuration
green flashing Actual configuration is determined
Orange flashing Target configuration is determined
Red flashing a required station missing
One station too many
Target configuration ≠ Actual configuration
red continuous light No SWD line present
No 15 V DC device voltage present
Config
Off no project configuration present, because e.g.
• Initial Commissioning or
• Program in easy806-SWD was deleted
green continuous light Target configuration = Project Configuration
Green flashing The station of the project configuration was replaced by a
compatible station in the target and actual configuration.
red continuous light Target configuration ≠ Project Configuration
LED
Status
LED device Off no 15 V supply voltage
green flashing Waiting for addressing
green fast flashing Error on station and diagnostic alarm is 1
green continuous light Station matches the target configuration.
