Eaton Network-M3 - Page 102

Settings
Contextual help of the web interface – 102
•
•
•
•
•
•
•
•
•
•
•
•
•
•
Address - hostname or IP address for the RADIUS server
UDP port - the UDP port for the RADIUS server (1812 by default)
Time out (s) - length of time the client waits for a response from the RADIUS server
Retry count - the number of time a connection is retried
Secondary server
Name -descriptive name for the RADIUS server
Secret - a shared secret between the client and the RADIUS server
Address - hostname or IP address for the RADIUS server
UDP port - the UDP port for the RADIUS server (1812 by default)
Time out (s) - length of time the client waits for a response from the RADIUS server
Retry count - the number of time a connection is retried
NAS
Identifier - descriptive identifier for the radius server to identify the device
IP - IP address of the card or a domain name ( FQDN )
2. ClickSave.
b Profile mapping
Note: The radius protocol supported by the card is PAP
