Network Management Card – User Manual 34003991XT_EN/JC Page 127/143
Automatic Bypass switch (Q4S) open Automatic Bypass switch (Q4S) closed
Bypass AC frequency out of tolerance Bypass AC frequency OK
Automatic Bypass fault Automatic Bypass OK
Automatic Bypass overload Automatic Bypass load OK
Automatic Bypass over temperature Automatic Bypass temperature OK
Bypass AC phase out of tolerance Bypass AC phase OK
Automatic Bypass thermal overload Automatic Bypass load OK
Load not protected - On Automatic Bypass Load protected - Return from Bypass
Bypass AC voltage out of tolerance Bypass AC voltage OK
Battery switch (QF1) open Battery switch (QF1) closed
Manual Bypass switch (Q3BP) closed Manual Bypass switch (Q3BP) open
UPS on manual bypass
Inverter limitation Inverter end of limitation
Inverter fuses blown Input fuses OK
Inverter fault Inverter OK
Inverter overload Inverter load OK
Inverter overtemperature Inverter temperature OK
Inverter short circuit Inverter OK
Inverter thermal overload Inverter load OK
Output switch (Q5N) open Output switch (Q5N) closed
Load short circuit Load OK
Single wave load fault Load OK
Negative DC bus too high Negative DC bus OK
Positive DC bus too high Positive DC bus OK
Rectifier fault Rectifier OK
Negative DC bus too low Negative DC bus OK
Positive DC bus too low Positive DC bus OK
Protection Lost Protection OK
Redundancy Lost Redundancy OK
Normal AC NOK Normal AC OK
Low battery Battery OK
UPS communication failed UPS communication restored
UPS data base not available UPS data base OK
UPS on battery UPS on normal AC
Emergency button ON Emergency button OFF
Fan fault Fan OK
Load not powered Load powered
UPS internal fault UPS OK
Battery fault Battery OK
UPS overload UPS returns to normal load
UPS over temperature UPS temperature OK
