Eaton Network-MS User Manual

www.eaton.com
Network
Management Card
(Network-MS)
User Manual
Network Management Card – User Manual 34003991XT_EN/JC Page 134/143
8.2.3 TRAPS table: (1.3.6.1.4.1.705.1.11)
SNMP traps are sent when alarms appears and disappears.
Level 1: informational, 2: major, 3: critical
MIB TRAP Trap # Level
upsmgBatteryFault Trap 1 Level 3
upsmgBatteryOK Trap 2 Level 1
upsmgAtLowBattery Trap 5 Level 3
upsmgFromLowBattery Trap 6 Level 1
upsmgChargerFault Trap 7 Level 3
upsmgChargerOK Trap 8 Level 1
upsmgOnBattery Trap 11 Level 2
upsmgReturnFromBattery Trap 12 Level 1
upsmgOnByPass Trap 13 Level 2
upsmgReturnFromByPass Trap 14 Level 1
upsmgUtilityFailure Trap 17 Level 2
upsmgUtilityRestored Trap 18 Level 1
upsmgOverLoad Trap 21 Level 3
upsmgLoadOK Trap 22 Level 1
upsmgOverTemperature Trap 23 Level 3
upsmgTemperatureOK Trap 24 Level 1
upsmgOffToStart Trap 29 Level 2
upsmgOffInProgress Trap 31 Level 3
upsmgCommunicationFailure Trap 37 Level 3
upsmgCommunicationRestored Trap 38 Level 1
upsRedundancyLost Trap 65 Level 2
upsRedundancyOK Trap 66 Level 1
upsProtectionLost Trap 67 Level 2
upsProtectionOK Trap 68 Level 1
If the Environment Sensor is detected, the following information is managed:
upsEnvironmentComFailure Trap 53 Level 2
upsEnvironmentComOK Trap 54 Level 2
upsEnvironmentTemperatureLow Trap 55 Level 2
upsEnvironmentTemperatureHigh Trap 56 Level 2
upsEnvironmentTemperatureOK Trap 57 Level 2
upsEnvironmentHumidityLow Trap 58 Level 2
upsEnvironmentHumidityHigh Trap 59 Level 2

Eaton Network-MS Specifications

General

Manufacturer	Eaton
Model	Network-MS
Category	Network Card
Interface	Ethernet
Data Rate	10/100 Mbps
SNMP Traps	Yes
Web Interface	Yes
Compatibility	Eaton UPS systems
Protocols	HTTP, SNMP
Communication	SNMP
Connectors	RJ45
Power Supply	Powered by UPS slot
