Network Management Card – User Manual 34003991XT_EN/JC Page 135/143
upsEnvironmentHumidityOK Trap 60 Level 2
upsEnvironmentInput1Closed Trap 61 Level 2
upsEnvironmentInput1Open Trap 62 Level 2
upsEnvironmentInput2Open Trap 64 Level 2
upsEnvironmentInput2Closed Trap 63 Level 2
The level is used to select traps to be sent to the supervisor. This adjustment is available from the “Notified
applications” page
8.2.4 EATON Powerware MIB
The Card implements the full Eaton Powerware MIB (PowerMIB), including alarm tables. The Eaton traps are
sent. The Eaton Powerware MIB access path is 1.3.6.1.4.1.534.
Table is an abbreviated list of objects from the PowerMIB. The UPS output/load segment controls objects and the
entire MIB description is available at http://powerquality.eaton.com/Support/SoftwareDrivers.
MIB Object SNMP Format Add.path
xupsIdentManufacturer String {1.1.0}
xupsIdentModel String {1.2.0}
xupsIdentSoftwareVersion String {1.3.0}
xupsIdentOemCode Integer {1.4.0}
xupsBatTimeRemaining Seconds {2.1.0}
xupsBatVoltage Volts DC {2.2.0}
xupsBatCurrent Amps DC {2.3.0}
xupsBatCapacity Percent {2.4.0}
xupsBatteryAbmStatus Integer {2.5.0}
xupsBatteryLastReplacedDate String {2.6.0}
xupsInputFrequency 0.1 Hertz {3.1.0}
xupsInputLineBads Integer {3.2.0}
xupsInputNumPhases Integer {3.3.0}
xupsInputTable {3.4.0}
xupsInputPhase Integer {3.4.1.1.x}
xupsInputVoltage RMS Volts {3.4.1.2.x}
xupsInputCurrent RMS Amps {3.4.1.3.x}
xupsInputWatts Watts {3.4.1.4.x}
xupsInputSource Integer {3.5.0}
xupsDualInputStatus Integer {3.6.0}
