Network Management Card – User Manual 34003991XT_EN/JC Page 138/143
xupsTestBatteryStatus Integer {8.2.0}
xupsLastGeneralTest Integer {8.3.0}
xupsLastGeneralTestResult Integer {8.4.0}
xupsConfigOutputVoltage RMS Volts {10.1.0}
xupsConfigInputVoltage RMS Volts {10.2.0}
xupsConfigOutputWatts Watts {10.3.0}
xupsConfigOutputFreq 0.1 Hertz {10.4.0}
xupsConfigDateAndTime String {10.5.0}
xupsConfigLowOutputVoltageLimit RMS Volts {10.6.0}
xupsConfigHighOutputVoltageLimit RMS Volts {10.7.0}
xupsConfigInstallDate String {10.8.0}
xupsTopologyType Integer {13.1.0}
xupsTopoMachineCode Integer {13.2.0}
xupsTopoUnitNumber Integer {13.3.0}
xupsTopoPowerStrategy Integer {13.4.0}
8.3 Authentication Configuration Example
8.3.1 RADIUS
A IP card is running with the 166.99.224.96 IP address.
A freeradius (version 1.1.7-r0.0.2) is running (IP address:166.99.224.129, port :1812), with the following
configuration:
• clients.conf file: allows NAS (NMC card) with an address in the 166.99.224/8 network to send requests
to the server (shared secret between the server and the NMC cards: eaton123)
client 166.99.224.0/8{
secret = eaton123
shortname = nmc
require_message_authenticator = no
}
• users.conf file: allows (with Service-Type attribute) the access to the NMC cards as an administrator
for the user:
o name: “admin”,
o password "myPassword "
