2.4 Sensor installation (option)
The Environment sensor is available as an option for the Network Management Card and is available from
EATON (EMP).
The sensor allows remote monitoring of the UPS's environment through regular measurements: temperature,
humidity, status of two external contacts. It also enables notification of alarms (e-mail, trap SNMP) according to
pre-programmed thresholds.
It is connected to the Service port (Settings/Sensor) directly on the Network Management Card with a standard
Ethernet cable (10 meters maximum).
Recognition is automatic. Supervision and configuration are performed via a menu that can be accessed directly
from the home page.
