Network Management Card – User Manual 34003991XT_EN/JC Page 126/143
Inverter limitation Inverter end of limitation
Inverter overload Inverter load OK
Inverter over temperature Inverter temperature OK
Inverter thermal overload Inverter load OK
Negative DC bus too high Negative DC bus OK
Positive DC bus too high Positive DC bus OK
Negative DC bus too low Negative DC bus OK
Positive DC bus too low Positive DC bus OK
Output switch (Q5N) open Output switch (Q5N) closed
Normal AC NOK Normal AC OK
UPS on battery UPS on normal AC
UPS overload UPS returns to normal load
UPS over temperature UPS temperature OK
Fan fault Fan OK
UPS communication failed UPS communication restored
8.1.2 Table of UPS events
List of time dated informations
Alarm on Alarm off
Battery fuse blown Battery fuse OK
Battery temperature fault Battery temperature OK
No Battery Battery present
Battery charger fault Battery charger OK
Charger temperature fault Charger temperature OK
MAX charger voltage fault Charger voltage OK
MIN charger voltage fault Charger voltage OK
End of Warranty LCM message OK
End of battery life LCM message OK
End of life of the wearing parts LCM message OK
Outlet 1 open Outlet 1 closed
Outlet 2 open Outlet 2 closed
Chopper fault Chopper OK
Normal AC switch (Q1) open Normal AC switch (Q1) closed
Normal AC frequency out of tolerance Normal AC frequency OK
Normal AC fuses blown Normal AC fuses OK
Normal AC module fault Normal AC module OK
Normal AC voltage out of tolerance Normal AC voltage OK
Site wiring fault Site wiring OK
