• Application Name: Given by the application at subscription time.
• Output: number of the UPS output from which the client is powered.
• Configuration: shows where the parameters of the Intelligent Power Protector come from: Local
(coming from the application) or Central (coming from the card).
The
Central shutdown configuration is available by clicking on the Configuration link.
• Shutdown duration: the shutdown duration necessary to properly shutdown the computer.
• Shutdown after: the time available to the user from the power failure until the launch of the shutoff
sequence of the UPS and equipment.
• Connected: This value is set to YES if the notified application connects through TCP protocol.
Many actions are available on this page:
• Remove: Depending on the kind of application, the selected ones will definitively disappear from the
table as SNMP applications, or they will disappear and automatically re-subscribe as Intelligent Power
Protector applications.
• Utility failure Test: Two alarms, 'Utility failure' and 'Utility restored' spaced 60 seconds apart, will be sent
to the applications selected, making sure that the applications can be reached over the network.
• Shutdown Test: This test simulates a UPS low battery sequence. It enables an easy check to see if the
server protection works correctly.
- No intervention on the UPS is required.
- The applications selected will process the simultaneous alarms and perform an actual shutdown
sequence.
WARNING!
- This test will generate a REAL shutdown sequence of the selected servers on which the Intelligent Power
Protector application is running.
• Add NMS: allows an SNMP trap receiver to be added such as a Network Management System.
• Modify NMS: allows an SNMP trap receiver to be modified.
Both buttons open a new window where it is possible to enter the Application name, the Hostname or IP
Address, the trap port, the protocol version needed: V1, V3 or both, the Trap community (only used in
V1) and the filter on the several implemented MIBs.
