6 Technical Data 6.9 Braking resistances 159 DC1 Variable Frequency Drive 04/16 MN04020003Z-EN www.eaton.com
Table 31: Braking resistance – DC1 voltage class 230 V
Device Type
Size
Resistance value Braking resistance (Low duty) Braking resistance (High duty)
Type Type
R
Bmin
R
Brec
P
max
R
Brec
P
max
DF t
Brems
R
Brec
P
max
DF t
Brems
Ω Ω kW Ω kW % s Ω kW % s
Mains voltage 115 V
Supply voltage (50/60 Hz) U
LN
110 (-10 %) - 115 (+10 %) V
U
e
115 V AC, single-phase / U
2
230 V AC, three-phase (internal voltage doubler)
DC1-1D5D8NB-A20N
FS2 100 100 1.1 DX-BR3-100 100 0.2 18 22 DX-BR100-0K4 100 0.4 36 44
Mains voltage 230 V
Supply voltage (50/60 Hz) U
LN
200 (-10 %) - 240 (+10 %) V
U
e
230 V AC, single-phase / U
2
230 V AC, three-phase
DC1-127D0NB-A20N
FS2 100 100 1.5 DX-BR3-100 100 0.2 13 16 DX-BR100-600 100 0.6 40 48
DC1-127D0FB-A20N
DC1-12011NB-A20N FS2 50 50 2.2 DX-BR3-100 100 0.2 9 11 DX-BR050-720 50 0.72 33 39
DC1-12011FB-A20N
DC1-12015NB-A20N FS3 22 25 4 DX-BR024-720 24 0.72 18 22 DX-BR025-1440 25 1.44 36 43
Mains voltage 230 V
Supply voltage (50/60 Hz) U
LN
200 (-10 %) - 240 (+10 %) V
U
e
230 V AC, three-phase / U
2
230 V AC, three-phase
DC1-327D0NB-A20N
FS2 100 100 1.5 DX-BR3-100 100 0.2 13 16 DX-BR100-600 100 0.6 40 48
DC1-327D0FB-A20N
DC1-32011NB-A20N FS2 50 50 2.2 DX-BR3-100 100 0.2 9 11 DX-BR050-720 50 0.72 33 39
DC1-32011FB-A20N
DC1-32018NB-A20N FS3 24 25 4 DX-BR024-720 24 0.72 18 22 DX-BR025-1440 25 1.44 36 43
DC1-32018FB-A20N
DC1-32024NB-A20N FS3 20 20 5.5 DX-BR020-960 20 0.96 17 21 DX-BR025-1920 25 1.92 35 42
DC1-32024FB-A20N
DC1-32030NB-A20N FS4 15 15 7.5 DX-BR020-960 20 0.96 13 15 DX-BR027-2880 27 2.88 38 46
DC1-32030FB-A20N
DC1-32046NB-A20N FS4 10 10 11 DX-BR020-960 20 0.96 9 10 DX-BR012-5K1 12 5.1 46 56
DC1-32046FB-A20N
