Menu structure of CI 3000
101
Version 2.09 09. April 2014
The bottom line shows the current operating status of the selected LDS component. If the component is work
ing, detailed information on its status is given:
ALARM A minimum of one fault still exists.
I Operating archive has been created.
e / E EU archive has been created / and is active.
O CAN bus failure
F CAN bus fault
√ Communication enabled
Page 2: Software version
STATUSNd.nnn Heading and Node No. of LDS component
Typ XXXXXXXXX
Type of component
Version X.XX ← Software Version No.
S.Nr. XXXXXXXXXXXXXXXXXXXXX Serial No. of component
S Screen 7-3 Configuration
This screen is used to change station details such as name, ID and alarm priority for every LDS component
connected to the CAN bus.
CONFIGURATION Nd.Nd.nnn Heading and Node No. of LDS component
Name of component → Name of component
Item ID XXXXX → Item ID of component
Priority p Alarm priority of component
delete Remove LDS component from system:
Delete LDS component:
Displays prompt: Are you sure? No: ESC Yes: ↵
A station can only be deleted after it has been shut down and subsequently reported as failed or
manually shut down.
