Pin and Terminal Assignments of CI 3000 / SIOX
60
Version 2.09 09. April 2014
6.1.4 Terminal assignment for CAN bus
The terminals for connecting the store computer to the CAN bus are located on the underside of the device.
Warning - hazardous electrical voltage!
If mains voltage is connected to the CAN bus terminals,
this will result in the destruction of all components connected to the CAN bus!
Leads running of the CAN bus must be shielded (cable type: LiYCY 2x2x0,75 mm
2
)! As a general
rule, care should be taken to ensure that signal leads and leads carrying a supply voltage are routed
through separate cable channels.
Terminal No. Function Aderfarbe
1
2
3
4
SHLD (Shield)
CAN-GND
CAN-LOW
CAN-HIGH
Shield
green
brown
white
6.1.5 Terminal assignment for the interfaces
Terminal No. Function
SIOX power supply (SIOX SUPPLY)
91
92
93
94
95
Ground 9V
+9 V DC
Ground von 24 V
1)
+24 V DC
1)
Shield
SIOX interface OUT (data cable output, to first SIOX extension module)
Serial port (MODEM) for connecting a modem or the
PC software LDSWin
Serial port (COM2) for the connection of UA 30/Dixell controllers, LDS1 Gateways
AHT cases with external controllers,
M bus or as interface for building automation
Serial port (COM3) - CI 3100 only for the connection of UA 30/Dixell controllers
1)
for details of 24 V DC supply see section “Installation and Startup”
