ECKELMANN CI 3000 - Terminal Assignment for 230 V AC Power Supply; Terminal Assignment for 230 V AC Digital Inputs

Pin and Terminal Assignments of CI 3000 / SIOX
58
Version 2.09 09. April 2014
6.1.1 Terminal assignment for 230 V AC power supply
The connection provides the store computer with power and is located on the underside of the device.
Warning - hazardous electrical voltage!
Danger of electric shock! BEFORE and AFTER connection it must checked
that the 230 V AC supply cable is off load!
The device may only be connected to the provided mains power supply.
Terminal No. Function
N, L, PE Power supply 230 V AC (SUPPLY):
Nneutral conductor, phase 230 V AC, PE (ground conductor)
Connection to the power suppl
In order to fuse the power line a circuit breaker with the following parameters is recommended:
- Nominal current at 230 V AC: 6 A
- Tripping characteristic (type): B
Connection cable requirements
As the store computer is not equipped with an integrated disconnecting device in the form of a power switch, the
following must be implemented:
a) a switch or circuit breaker must be installed in the system or building installation,
b) this must be suitably positioned and easily accessible for the user, and
c) must be labelled as a disconnecting device for the equipment.
6.1.2 Terminal assignment for 230 V AC digital inputs
The two digital inputs are designed for installation monitoring, i.e. as meter inputs (230 V AC!) and are located
on the underside of the device.
Warning - hazardous electrical voltage!
Danger of electric shock! BEFORE and AFTER connection it must checked
that the 230 V AC digital inputs are off load!
Terminal No. Function
A1, A2 Digital input 1 (AL.1), 230 V AC (floating)
B1, B2 Digital input 2 (AL.2), 230 V AC (floating)
