Specifications of CI 3000 / SIOX
121
Version 2.09 09. April 2014
11 Specifications of CI 3000 / SIOX
For safety reasons and to guarantee important functions (e.g. alarm forwarding to a service centre
via modem) only accessories approved by Eckelmann are to be used with the store computer.
11.1 Electrical data
Warning - hazardous electrical voltage!
Danger of electric shock! Overvoltage category III / pollution degree 2:
All device connections designed for use with 230 V AC supply voltage
must be connected to the same phase conductor.
400 V AC between neighbouring connection terminals is not permitted!
Overvoltage category II / pollution degree 2 or
Overvoltage category II / pollution degree 1:
Different phase conductors may be used.
400 V AC between neighbouring connection terminals is permitted!
CI 3000 Store Computer SIOX Extension Module
Power supply 230 V AC, 200 - 265 V AC,
50/60 Hz
24 V DC / 9 V DC,
Supplied by CI 3000
Rated power 24 VA 2 W
Leakage current over PE Max. 1 mA
Relay outputs
1)
3 x changeover for reporting system,
floating:
2 x 230 V AC min. ≥10 mA
Lastart: max. 6 A (ohmic)
max. 3 A (inductive)
(24 V DC / max. 5 A DC)
For outputs PRIO.1 and PRIO.2 with
bistable relays and 5 min. operate delay
on device shutdown
1 x 230 V AC min. 5 V / 10 mA
max 230 V AC / 6 A
max. 24 V DC / 5 A
For output AUX,
e.g. for acoustic signal transmitter
4 x N.O., 4 x changeover
floating:
2 x 230 V AC, min. 5 V / 10 mA
max 230 V AC / 6 A
max. 24 V DC / 5 A
Digital inputs 2 x 230 V AC, floating, for external alarms
(inputs AL.1 and AL.2)
12 x 230 V AC / 24 V S0 meter inputs
internally convertible by jumper
2)
,
floating
