ECKELMANN CI 3000 - M-Bus-Gateway Status Leds

Installation and Startup of CI 3000 / SIOX
48
Version 2.09 09. April 2014
The following transmission rates and distances are possible with the cable type J-Y(ST)Y 2x2x0.8 mm:
Transmission rate No. of M-bus meters Length
300 Baud ≤ 10
≤ 20
max. 4000 m
max. 3200 m
2400 Baud ≤ 10
≤ 20
max. 5100 m
max. 3200 m
5.8.1 M-Bus-Gateway status LEDs
Green Supply voltage 11 .. 28 V DC (Article number: KGLNT23024)
Red Over-current (short circuit)
yellow End device transmitting
