ECKELMANN CI 3000 - Menu 4 Message Log (Event Log)

Menu structure of CI 3000
75
Version 2.09 09. April 2014
S Screen 3-a
ARCHIVE Pos: XXXXX Shows archived data
ARCHIVE Pos. XXXXX
Mi 19.12.05 12:06
Date, time
Zone 1: OCDGA ttt°C Zone 1: Temperature zone 1
- O, C, D, G, A:
- Abbreviation for different operating conditions of the refriger point ttt°C: - Display tempera
ture 3 digit in °C
Zone 2: OCDGA ttt°C
one Zone only: OCDGA ttt°C
Zone 2: Temperature zone 2
- O, C, D, G, A:
- Abbreviation for different operating conditions of the refriger point ttt°C: - Display tempera
ture 3 digit in °C
Scroll with the up and down cursor keys (↑) (↓) to view certain data. The ENTER key can also be pressed to
view data. Enter the date and time and confirm with the ENTER key. Press the left cursor key (←) to return to
the archive.
Automatic clock adjustment for daylight saving changes is ignored for archiving. Records shown are
all recorded at normal winter time!
Abbreviations for refrigeration point status:
O = ON
C = Cooling
D = Defrosting
G = Door
A = Alarm
8.1.5 Menu 4 Message Log (Event Log)
Messages/events can be selected from this list with the up and down cursor keys (↑) (↓).
MSG/ALARM XXX Prio p XXX: Message/Fault No. / Prio p: Message priority p
Node Name Name of component
Item ID XXXXX → Refrigeration point type. Continue to Screen 4-a
Text Message/alarm text
S Screen 4-a
MSG/ALARM XXX Nd.nnn xxx: Message/Fault No. /
Nd.nnn: Node No. or CAN bus address
Text Message/alarm text
dd.mm.jj hh:mm ON ↔ Message receive date/ and time
dd.mm.jj hh:mm OFF Message send date/ and time
Use the up and down cursor keys (↑) (↓) to scroll through the message log in chronological order. The left and
right cursor keys (←) (→) can be used to scroll pagewise and display additional messages for the same LDS
component.
