ECKELMANN CI 3000 - 7.3 Remote Operation and Parameter Setting

Operation of CI 3000
70
Version 2.09 09. April 2014
7.3 Remote operation/parameter setting of a LDS component
The LC display contains 4 lines of 20 characters. If a menu or screen contains more than 4 lines, the cursor
keys can be used to scroll through the remaining lines.
Main menu
4 Messages ↑
5 Remote control
6 Store computer ↓
Entry block must first be deactivated before parameters can be set.
In the Main Menu of the Store Computer or AL 300 Operator Terminal, open submenu 5 Remote Operation.
This displays the following screen:
REMOTE CONTROL Kn.nnn
Node Name ↑
Item ID XXXXX↓
The LDS component wanted required can be selected using the cursor keys (↑) and (↓) or by entering its CAN bus
address (node No. nnn) with the numeric keys. Press the ENTER key to open the LDS component selected. This
displays the main menu of the LDS component (UA 400 case controller in the example shown):
REFR. PT. Pos: XXXXX
1 Actual Values ↑
2 Setpoints
3 Clock
4 Messages
5 Archive
6 Configuration ↓
