Function of CI 3000
32
Version 2.09 09. April 2014
4.13 Integration of refrigeration controllers
The following external controllers can be integrated via Modbus into the LDS system and archived.
S Compact case controllers
UA 30 RC / UA 30 RS
connected via the store computer's COM2 interface using an RS232-RS485 converter.
The status as well as the configuration of the integrated compact case controllers M1..M50 is carried
out via the store computer:
- For the status and temperature indication of the individual refrigeration points see menu item 7-5
- For the configuration of the name as well as the position indicator for the individual refrigeration
points see menu item 7-6
S Case controllers of the LDS1 system
UA11/UA111/ UA121/UA131/UA141/UR141/UA132
The status as well as the configuration of the case controllers of the LDS1 system M1..M48 inte
grated via the LDS1 gateway are carried out via the store computer:
- For the status and temperature indication of the individual refrigeration points see menu item 7-5
- For the configuration of the name as well as the position indicator for the individual refrigeration
points see menu item 7-6. For detailed information see the operating manual ”LDS1 Gateway”.
Connection to the store computer:
CI 3000: connected via the COM2 interface using a RS232-RS485 converter.
CI 3100: connected via the COM3 interface.
For more detailed information, see ”Connecting compact case controllers” in Section 5.7.
4.14 Integration of Third-party case controllers
The following third-party case controllers can be integrated into the LDS system and archived. In addition, the
temperature archives (see menu 6-3) of the following controllers can be viewed on the store computer.
S Compact case controllers from Dixell via Modbus:
Connection to the store computer:
CI 3000: connected via the COM2 interface using a RS232-RS485 converter.
CI 3100: connected via the COM3 interface.
For more detailed information, see ”Connecting compact case controllers” in Section 5.7.
S AHT cases with Danfoss controllers:
Connected via the store computer's COM2 interface and via Modbus
S AHT cases with Wurm controllers:
Connected via the store computer's COM2 interface and a gateway
For more detailed information, see ”Connection of AHT cases in the LDS system”.
4.15 FAQs - Frequently asked questions and answers
Further information about the components described in this operating instruction is provided in the FAQs
(Frequently asked questions) on the E*LDS documentations CD.
