Pin and Terminal Assignments of CI 3000 / SIOX
59
Version 2.09 09. April 2014
6.1.3 Terminal assignment for 230 V AC relay outputs
The two relay outputs PRIO1/PRIO2 can be used for sending alarm messages. The multifunctional output AUX
can be freely configured (see table). The terminals are located on the underside of the device.
Warning - hazardous electrical voltage!
Danger of electric shock! BEFORE and AFTER connection it must checked
that the 230 V AC relay outputs are off load!
Low voltage and safety extra-low voltage must not be applied together
at the relay outputs 15/16/18, 25/26/28 and 35/36/38.
Falls die Alarmierung über ein Telefonwahlgerät mit den dafür vorgesehenen abfallverzögerten
Alarmkontakten PRIO1/PRIO2 erfolgt so sind diese einer zyklischen Kontrolle zu unterziehen um
sicherzustellen, dass die Kontakte auch bei Spannungsausfall noch melden.
In order to fuse the cable and relay outputs a circuit breaker with the following parameters is recom
mended for each relay output:
- Nominal current at 230 V AC: 6 A
- Tripping characteristic (type): B
Terminal No. Function
15 (common)
16 (N.C.)
18 (N.O.)
Multifunctional output AUX: Can be configured (menu 6-1-4-1) as follows:
- Horn
- Modem hardware reset
- Additional alarm relay with the priority PrioX3, PrioX4, PrioX5,
PrioX6, PrioX7, PrioX8 or PrioX9
or
- For switching the modem to the DDC (T-connector required)
25 (common)
26 (closed by alarm)
28 (opened by alarm)
Alarm relay PRIO2: Alarm for messages with priority 2
35 (common)
36 (closed by alarm)
38 (opened by alarm)
Alarm relay PRIO1: Alarm for messages with priority 1
Light switch
(for switching of a protective circuit breaker)
1, 2 For switching of contactor with suppressor (LIGHT)
