Menu structure of CI 3000
100
Version 2.09 09. April 2014
8.1.8 Menu 7 Monitoring
MONITORING
1 Overview Overview of number of configured and active LDS components
2 Status Detailed status of all LDS components
3 Configuration Configure name and item ID of all LDS components
4 System Alarms Configure CI 3000 Store Computer system alarms
5 Status UA30/DIX Status of the compact controller connected via COM2
6 Config.UA30/DIX Configuration of the compact controller connected via COM2
7 Status AHT Status of the AHT cases connected via COM2
8 Status AHT DANFOSS Status of the AHT/Danfoss cases connected via COM2
S Screen 7-1 Overview
This screen shows the current station monitoring status.
OVERVIEW
Aktivated XXX Number of activated LDS components
Present XXX Number of available LDS components
Not present XXX Number of failed LDS components
The number of LDS components registered via the CAN bus (activated), the number detected as functional
(available) and the number detected as failed are shown.
Refrigeration points that have been shut down and removed from station monitoring (manual shut
down) are counted among the failed stations.
S Screen 7-2 Status
Select an LDS component either by entering its CAN bus address and confirming with the ENTER key or by
using the up and down cursor keys (↑) (↓).
Page 1: Show current status of CAN bus stations
STATUSNd.nnn Heading and Node No. of LDS components
Name of LDS component Name of LDS component
Item ID XXXXX → Item ID of LDS component. Move to Page 2 – Software Version
Operating ALARM IEOF√
Shut down manually
Component alarmed
Status:
Component operating
Refrigeration point shut down manually
Component alarmed as failed
To Next Page
