Menu structure of CI 3000
111
Version 2.09 09. April 2014
8.1.11 Menü 0 HVAC Overview
Screen showing overview of store HVAC data.
Screen will only be shown when DDC (digital direct control) is connected to the LDS System.
HVAC OVERVIEW
Außentemp. xx.x°C Outside temperature
Soll Raumt.VR xx.x°C Salesroom (VR=SR=sales room) temperature setpoint
Raumtemp VR xx.x°C Salesroom (SR) actual temperature
CO2 VR xxp Salesroom (SR) CO
2
level
Soll Raumt.KB xx.x°C Cooling zone (KB=CZ=cooling zone) temperature setpoint
Raumtemp. KB xx.x°C Cooling zone (CZ) actual temperature
Raumt. Lager xx.x°C Storeroom actual temperature
Zulufttemp. xx.x°C Supply air actual temperature
Abluftemp. xx.x°C Exhaust air actual temperature
Soll Zuluftt. xx.x°C Indication of the setpoint temperature of the supply air
WWBoil. oben xx.x°C Indication of the upper temperature for the boiler's warm water
WWBoil. unten xx.x°C Indication of the lower temperature for the boiler's warm water
xxx yyy ZLG: Btxsc Indication of central ventilation device (ZLG) operating mode:
xxx kbv Cooling sales area
HBV Heating sales area
yyy sbn Summer operation adjoining room
WBN Winter operation adjoining room
ZLG: B ZLG operation
t ZLG operation due to temperature requirements
x ZLG operation due to external requirements
s ZLG operation due to flushing
c ZLG operation due to CO
2
requirements
