Pin and Terminal Assignments of CI 3000 / SIOX
61
Version 2.09 09. April 2014
6.2 SIOX - Extension module terminal diagram
Warning - hazardous electrical voltage!
In order to guarantee reverse voltage protection,
only coded mating plugs are to be used on the assembly connections.
The following figure shows a SIOX extension module without switches:
Detailed safety instructions and information on the configuration of the plug-in jumpers for the digital
inputs is provided in chapter 5.5.2.
A description of the connection and terminal configuration for the digital inputs, the relay outputs and the SIOX
interface is provided on the following pages.
