Menu structure of CI 3000
74
Version 2.09 09. April 2014
S Screen 1-a
Display Page 2 - Alarm still active Entry
ALARM XXX Nd.nnn Heading with Node No. of alarm-generating component
↑←↓
Node Name Name of alarm-generating component
dd.mm.jj hh:nn ON ← Time of alarm occurrence
Use cursor keys to move to next alarm
Display Page 2 - Alarm terminated
ALARM XXX Heading with Node No. of alarm-generating component
↑←↓
Node Name Name of alarm-generating component
dd.mm.jj hh:nn ON ←
Time of alarm occurrence
dd.mm.jj hh:nn OFF Send time stamp. Use cursor keys to move to next alarm
8.1.3 Menu 2 General Overview
This screen is used for quick display of current operating status and temperature of the separate refrigeration
points.
OVERVIEWPos:xxxxx Heading with item ID of refrigeration point Entry
Overview of refrigeration point with 1 zone
Node Name Name of refrigeration point
↑↓
Status XXX°C Current controller status and current temperature:
Status may be shown as Cooling, Defrost or Alarm.
Overview of refrigeration point with 2 zones
Node Name Name of the refr. point
↑↓
Status 1 Z1: XXX°C Current controller status and current temperature for Zone 1:
Status may be shown as Cooling, Defrost or Alarm.
Status 2 Z2: XXX°C Current controller status and current temperature for Zone 2:
Status may be shown as Cooling, Defrost or Alarm.
On opening this screen, the case or coldroom having the lowest CAN bus address (0 to 99) is shown first. Use
the up and down cursor keys (↑) (↓) to move to the next refrigeration point and back.
8.1.4 Menu 3 Archive
Use the up and down cursor keys (↑) (↓) to scroll through this list and select EU Archives that have been
created and stored.
ARCHIVE Nd.nnn Shows refrigeration point data archived on Store Computer
Node Name Name of refrigerated display case
Position XXXXX → Refrigerated display case location and type. Continue to Screen 3-a
Current status and temperature for Zone 2
Press the right cursor key (→) to open the records list for the selected archive.
