Menu structure of CI 3000
76
Version 2.09 09. April 2014
8.1.6 Menu 5 Remote Control
This screen is used to select LDS components that are to be remotely operated. Selection can be made in two
ways:
‐ By entering the CAN bus address of the LDS component and confirming with the ENTER key.
‐ By the up and down cursor keys (↑) (↓).
After selecting the station wanted, press the ENTER key to start terminal mode and show the main menu for
the selected component. After that the operating principle with menus and screens is the same for all LDS com
ponents.
To terminate terminal mode, press the ESC key in the main menu for the respective component.
REMOTE CONTRL Nd.nnn Nd.nnn = Node No.
(CAN bus address of component wanted)
Entry
Node Name Name of LDS component ↑, ↓,
or number
Item ID XXXXX Item ID of component
Terminal mode will be closed automatically if no key is pressed for 10 minutes and the main menu
or alarm log of the CI 3000 Store Computer will be displayed.
Any entry made at the time by the user but not yet confirmed will be cancelled.
8.1.7 Menu 6 Store Computer
STORE COMPUTER
1 Configuration Store computer configuration submenu
2 Meter Values Show meter readings
3 Temperature-Arch. Show temperature archive (controller dependent)
To Next Page
