Installation and Startup of CI 3000 / SIOX
45
Version 2.09 09. April 2014
5.6 Special functions for startup
A number of special functions can be invoked by combinations of keys:
‐ Triggering of test alarms:
Prio X1: by simultaneously pressing the buttons MODE and 1
Prio X2: by simultaneously pressing the buttons MODE and 2
Prio X3: by simultaneously pressing the buttons MODE and 3
…
Prio X9: by simultaneously pressing the buttons MODE and 9
‐ Simultaneously press the MODE and ESC and 6 keys
to delete the operating archives and reorganize archive management (is entered in message log).
‐ Simultaneously press the MODE and ESC and 8 keys to perform restart.
Frequent restarting while the CI 3000 Store Computer is powering up (about 2 min.) can result in
errors in archive management.
Praxis tip
Following the completion of commissioning, delete the operating archive using MODE and ESC and 6 -
for approx. 2 min following this, do not switch off ANY LDS components!
