Menu structure of CI 3000
104
Version 2.09 09. April 2014
S Screen 7-7 Status AHT
This menu contains display screens reserved for use by service personnel.
STATUS AHT Entry Default
Status → Continue to Screen 7-7-a → -
Delay 5 Delay in minutes ↑, ↓, (0..99) 5
S Screen 7-7-a
This screen will only be displayed when AHT is selected in Screen 6-1-9 and an AHT gateway is connected.
STATUS AHT Mxxx
Name X XXXXXX Name refrigeration point (can only be entered in LDSWin)
iiiii °C sssss °C eee iiiii = Actual temperature in °C
sssss = Temperature setpoint in °C
eee = On time in minutes
C D Alarm tttt Status: C = Cooling / D = Defrost / Alarm
tttt = Communication timeout, failure alarmed at 0
S Screen 7-8 Status AHT Danfoss
This menu contains display screens which are reserved for the service personnel.
This screen is only shown when Danfoss/AHT is selected in the screen 6-1-9.
STATUS DANFOSS M:xx Eingabe Vorgabe
Position → Position des Kompaktreglers, weiter zur Maske 7-8-a →
S Screen 7-8-a
This screen is only shown when Danfoss/AHT is selected in the screen 6-1-9.
STATUS DANFOSS M:xx
Type -- Controller type
Version Version of the Danfoss controller, back with ← button
Setp: x°C Act: x°C Temperature setpoint and actual value
