EDAN H50 - Connection Board

80 pages

To Next Page

To Previous Page

H50/H51 Hematology Analyzer User Manual Measurement Principle

- 9 -

2.2.4 Connection board

The connection board is located at the back of the instrument and allows different types of

connections described below.

4 USB Ports

Serial Link RS232

Not Used

P/S 24V

TCP/IP Port
