H50/H51 Hematology Analyzer User Manual Measurement Principle
- 10 -
2.2.5 External power supply Adapter
H50/H51 Analyzer is supplied with an external power supply adapter.
100-240 VAC; 50/60 Hz; Single phase with ground
NOTE:
If the power cord provided with the instrument needs to be replaced, the new cord must
be in compliance with the local regulation and the instrument specification in matter of
consumption.
2.2.6 Printer
H50/H51 Analyzer is not delivered with the printer. The instrument is equipped already with
PCL3 & PCL6 standard printer drivers which cover a large selection of printer models, such as
HP Laserjet Professional P1106.
2.2.7 External Barcode reader
An external barcode reader (model OPTICON - C37) can be connected to an USB port of
H50/H51 Analyzer. It only allows entering the following information automatically:
¾ Sample identification SID
¾ Reagent identification (LYSE, CLEANER and DILUENT)
¾ QC and calibration lot number
