H50/H51 Hematology Analyzer User Manual Specifications
- 65 -
Appendix 1 Specifications
A1.1 Environment Requirements
H50/H51
Hematology
Analyzer
Usage
Temperature
18
– 32 °C
Humidity
ʇ80%
Transport and
Storage
Temperature
-10°C to 50°C
Humidity
ʇ80%
A1.2 Analyzer Specifications
Size
406mm x 275mm x 430mm (approx.) (depth × width × height)
Weight
13kg (approx.)
LCD Touch
-screen
10
.4 inch (800mm*600mm)
Connection
5 USB ports
Ethernet-RJ45
Serial LIS-SUB D9
A1.3 Performance Specifications
Sample Volume
15.6
μL (WB Mode and CAP Mode)
20 μL (PD Mode); Dilution Rate:1:15
Throughput
1test/ 60s
A1.4 Power Adapter
Size
175mm x 72mm x 35mm (approx.) (depth × width × height)
Weight 0.6kg (approx.)
Power
Input
100-240VAC, 50/60Hz, 2.0A
Output
24VDC, 6.67A, 160W Max.
