Chapter 5

| System Settings

Diagnostics

– 95 –

 BLE Scan — (EAP101 and EAP104 only) Scans for all BLE devices, including

these four types: EddyStone-UID, EddyStone-URL, EddyStone-TLM, and

ibeacon.

Figure 69: BLE Scan

Diagnostics

The Diagnostics page provides Ping, Traceroute, Nslookup, and Speed Test tools

for troubleshooting connectivity problems.

Ping Enter a hostname or IP address and click to run the ping tool.

Figure 70: Network Utilities - Ping

Traceroute Enter a hostname or IP address and click to run the traceroute tool.

Figure 71: Network Utilities - Traceroute
