STP-iS1607 Series Turbomolecular Pump
MT-94E-001-C
Page 110
5
SERIAL COMMUNICATION PROTOCOL
5.4.14 ReadModFonctWithWarning
Function: Reads the pump operation mode, errors and warnings being detected.
Transmission Frame:
PCSIM
Stx
0
0
1
?
m
Etx
LRC
SIMPC
Ack
PCSIM
Ack
SIMPC
Stx
0
0
1
Sp
m
Parameter 1 to 82
*1
Etx
LRC
Parameter
Item
Data format
Remark
1
Pump operation mode
8-bits hexadecimal
coded ASCII
See Table 26
2
WARNING being detected
16-bits hexadecimal
coded ASCII
See Table 28
3
The number of errors detected
8-bits hexadecimal
coded ASCII
Up to 80 errors
*1
4 to 83
*1
Error 1
8-bits hexadecimal
coded ASCII
*2
Error 80
*1
8-bits hexadecimal
coded ASCII
*1
The maximum number of errors may differ depending upon the software version of the STP pump. It is recommended that
an application be designed as variable-length data.
*2
Value corresponding to the error message is transmitted. (see Table 24 and Table 25)
The recent error has the largest parameter number. When the number of errors being detected is under the maximum
number, the value of parameter that is larger than the number of errors being detected is set to 0.
