STP-iS1607 Series Turbomolecular Pump
MT-94E-001-C
Page 75
5
SERIAL COMMUNICA
TION PROTOCOL
5.2.3 Communication parameter setting
The factory setting of COM1 is shown in Table 17. To set communication parameters, use the STP-
Link (optional accessory) or the display unit iDT-001 or iDT-002 (optional accessory).
Communication
parameter
Factory setting
PC setting example
Baud rate
9,600 bps
1,200 to 56,000 bps
Bit length
8 bit
7, 8 bit
Stop bit
1 bit
1, 2 bit
Parity
None
None, Even, Odd
Driver type
RS232/RS485 single
RS232/RS485 single, RS485 multi
RS485ID
*1
1
1 to 127
Terminator
Not use
Not use, Use
*1
It is used in RS485 multi.
Table 17 - Communication parameters
