Edwards STP-iS1607 Series User Manual

STP-iS1607 Series Turbomolecular Pump
MT-94E-001-C
Page 15
2
TECHNICAL DATA
2.4 Control unit
The values shown below are typical. They are not guaranteed.
Item
STP-iS1607/iS1607C/iS1607B
STP-iS1607S/iS1607CS/iS1607BS
Input voltage
ACV
200 to 240
Allowable input voltage
fluctuation
%
± 10
Input power
VA
750 maximum
Input frequency
Hz
50/60 ± 2
Leakage current
mA
2.0 maximum
Input phase
Single phase
Main fuse specification
A
6.3
Current Ampere Interrupting Capacity
(AIC)
A
100
(250V AC 50/60 Hz)
Pollution degree
2
Installation category
Ⅱ
Motor driving system
3-phase d.c. brushless motor driver
Output frequency under normal operation
Hz
608 maximum
Panel indication LED
POWER
(Green LED)
FAILURE
(Red/Orange LED)
ROTATION
(Green/Orange LED)
Data
(Green LED)
Off-Line
(Orange LED)
Error
(Red LED)
Input/Output connector
AC POWER X1
(3 pins)
REMOTE X2
(25 pins)
COM1 X3
(9 pins)
STP-LINK X5
(8 pins)
