STP-LINK AND DISPLAY UNIT
6.2 Display unit
The "display unit" operates the STP pump, confirms the pump status or sets various settings. The
display unit iDT-001 and iDT-002 is equipped with an LCD and flat panel switches.
See the Instruction Manual of the "Display unit iDT-001" or "Display unit iDT-002" for the detailed
specification and operating methods.
Figure 50 - Display unit iDT-001 (iDT-002)
STP-Link
BRAKE
ACCEL.
STOP
START
NORMAL FAILURE
POWER
UP
DOWN
ENTER
SELECTRESET
65
98.4
132
122.5
