STP-iS1607 Series Turbomolecular Pump

MT-94E-001-C

Page 23

INSTALLATION OF THE STP PUMP

3.1.2 Installation area

Leave enough space for the followings in addition to that for the STP pump: (see Figure 10)

• Space for maintenance and inspection.

• Space for connecting cables.

CAUTION

DO NOT bend the power cable excessively and beware of any obstacles when installing the STP

pump. In addition, leave enough space to install other cables without bending them excessively.

Side view

Figure 10 - Space around the STP pump
