Edwards STP-iS1607 Series User Manual

STP-iS1607 Series Turbomolecular Pump
MT-94E-001-C
Page 123
5
SERIAL COMMUNICATION PROTOCOL
1. In case of time flag = 0
Parameter
Item
Data format
Remarks
a
Error Code
8-bits hexadecimal
coded ASCII
*1
b
Time flag
8-bits hexadecimal
coded ASCII
c
Pump running time
32-bits hexadecimal
coded ASCII
Unit: minute
d
Control unit running time
32-bits hexadecimal
coded ASCII
Unit: minute
*1
Value corresponding to the error is transmitted (see Table 24, Table 25）. When the number of errors being detected is
under the maximum number, the value of parameter that is larger than the number of errors being detected is set to FF
hex
.
Example:
In case of Disturbance X_H detection at
Pump running time = 5,000 minutes, control unit running time = 6,000 minutes
Parameter
a
b
c
d
ASCII
0
D
0
0
0
0
0
0
1
3
8
8
0
0
0
0
1
7
7
0
HEX
30
44
30
30
30
30
30
30
31
33
38
38
30
30
30
30
31
37
37
30
2. In case of time flag = 1
Parameter
Item
Data format
Remarks
a
Error Code
8-bits hexadecimal
coded ASCII
*1
b
Time flag
8-bits hexadecimal
coded ASCII
c
Error detection time
(Format：yymmddhhnn)
yy: The last two digits of the
year
mm: Month
dd: Day
hh: Hour (24-hour display)
nn: Minute
40-bits hexadecimal
coded ASCII
*2
d
[System reservation]
24-bits hexadecimal
coded ASCII
*1
Value corresponding to the error is transmitted (see Table 24, Table 25）. When the number of errors being detected is
under the maximum number, the value of parameter that is larger than the number of errors being detected is set to FF
hex
.
*2
Each value of time is transmitted as BCD form character string.
