Edwards STP-iS1607 Series User Manual

STP-iS1607 Series Turbomolecular Pump
MT-94E-001-C
Page 46
3
INSTALLATION OF THE STP PUMP
CAUTION
DO NOT place heavy objects on the cables or bend them excessively. Support each cable so as not
to apply direct force to the connectors or terminals. If any problem occurs in cables, connectors or
terminals, the STP pump may not function normally. DO NOT apply voltage to each connector pin
and DO NOT cause any short-circuiting between pins. Install cables so that personnel are not
exposed to risk of tripping or falling.
Connect the power cable to the "X1 AC POWER" on the control unit front panel.
