10-16 DICOM
Media review:
1. Connect the external media with DCM files to the system.
2. Select the data source in iStation screen, and the visible data will be shown.
If there are several kinds of data on the media, the system will ask you to select the format
from a dialog box.
Data Restore:
1. If the DICOM format data is backed up to external media, you can restore the data to the
system from the media.
2. Review the data stored in the external media.
3. Select the data to be restored in iStation.
4. Click
in the iStation screen.
NOTE: Only the system accessible media can be selected.
10.5 Showcase Recording
Showcase software can be employed for DICOM image file viewing.
When record DICOM files (both files backed up as DICOMDIR format and files transformed
into DICOM files by clicking [Send To]), the showcase can be recorded to the CDs together.
Insert a CD containing showcase software, the showcase runs automatically.
NOTE: To view the DCM files successfully, it is suggested to install NET Framework
(Visual Studio.Net) of a version later than 2.0, if your computer was installed
with TortoiseSVN.
10.6 DICOM Task Manager
DICOM Task Management is used to view task progress or manage tasks after sending
images for storage, print, or media storage.
For details on tast manager, see 9.6 Task Manager.
