8-4 Comments and Body Marks
8.2 Body Mark
The Body Mark (Pictogram) feature is used for indicating the exam position of the animal and
transducer position and orientation.
The system supports body marks for Dog, Cat, Equine, Bovine, Ovine or Other. You can
preset the system configured general body marks for each exam mode, also, you can
customize the body mark. For details, please refer to !11.5 Body Mark Preset".
8.2.1 Body Mark Operation Procedures
To add the first body mark:
1. Press <Body Mark> to enter the body mark status.
2. Select the body mark, adjust the position and direction of the probe icon.
3. Exit body mark mode˖
z Press the <Set> key to confirm the position and orientation of the probe marker and
exit the body mark mode.
z Press [Body Mark] again on the control panel.
z Press the [Esc] key to confirm the current operation and exit the body mark status.
8.2.2 Menu
Press <Menu> to display the body mark menu. You can:
Select Bodymark library
Move the cursor to menu title, and select the desired library.
Display
Click [Display] to display or hide the body mark added.
8.2.3 Adding Body Marks
To add the first body mark:
(1) Enter body mark mode˖
(2) Select the bodymark library through the menu title.
(3) Select the bodymark.
Move the cursor onto the desired bodymark to highlight your choice, and press <Set>
to add the selected bodymark; or rotate the multifunctional knob to view the
bodymarks.
(4) Press <Set> to confirm the selection.
(5) To adjust the probe position and orientation marker:
z Roll the trackball to place the probe marker at the correct position.
z Rotate the multifunctional knob to adjust the orientation.
z Press the <Set> key to confirm the position and orientation of the probe marker and
exit the body mark mode.
8.2.4 Moving Body Marks
You can move the body mark graphic to any desired position within the image area.
