3-8 System Preparation
3.10 External DVD
1. Connect the USB cable of the DVD recorder to the USB port on the ultrasound system
(all USB ports available).
2. Connect the power adapter of the DVD on the power supply.
3.11 Basic Screen and Operation
3.11.1 Basic Screen
The following diagram maps out the different areas in the screen:
logo
Hospital name
Animal Information
Accession#
Freeze
icon
Operator Exam time
Probe Acoustic power, MI/TI
Menu area Image area
Product Mode
Exam Mode
Image Parameters
Thumbnail
preview&
zoom
window
Cine Review Area
Bodymark & Comment
Thumbnail Area of Images Saved
Help information area System status icon
 Information Area
The information area displays manufacturer logo, hospital name, exam date & time,
acoustic power & MI/TI, freeze icon, animal information, probe model, current exam mode,
and accession #, etc. It can be preset whether to display the operator, animal gender, age,
ID, name etc. via [Setup]-> [System Preset]-> [General]. See “11.1.2 General” for detailed
preset procedures.
z Manufacturer logo
Manufacturer logo, displayed in the upper left corner of the screen.
z Hospital name
Displays the hospital name. Hospital name can be set via [Setup]-> [System Preset]-
> [Region].
