10-2 DICOM
3. Local TCP/ IP preset items are described as follows:
Name Description
Current Net Adapter To select network connection mode.
DHCP
/ Static
DHCP: IP address will be automatically obtained from DNS server;
Static: you need to enter the IP address.
IP Address IP address of the system.
Subnet Mask Used to set different network segment.
Gateway Used to set the gateway IP.
Note:
z The IP address of the system should not be occupied by other devices in the network,
or the DICOM function will fail.
z After you changed !Station Name", you need to restart the system to make the setting
effective (press the power button and select !Shut Down" and restart the system after
a while).
10.1.2 DICOM Preset
To set the DICOM service and server properties.
1. Press <Setup> to enter the [Setup] menu.
2. Select [DICOM Preset].
To Next Page
