System Preparation 3-9
z Exam time
Displays the exam time, including date and time. Exam time can be set via [Setup]->
[System Preset]-> [Region]. Exam time will be frozen with the frozen image.
z Acoustic power & MI/TI
Displays the acoustic power. Including the acoustic power, MI (Mechanical Index)
and TI (Thermal Index).
z Freeze icon
The freeze icon
means the image is frozen.
z Animal Information
Displays animal name, ID, gender and age etc. Enter the animal information through
the "Animal Info" screen. Or, import the saved animal data from iStation or the
DICOM Worklist server.
z Probe model
Display the currently-used probe model, or the default model.
z Exam Mode
Displays the currently used exam type, e.g. Abdomen, is displayed.
z Operator
Displays the operator!s name on the screen. This information is entered through the
[Animal Info] screen.
z Accession#
The accession # indicates exam number used in hospital information system. It can
be imported via DICOM or input manually.
Menu area
Include image menu, measurement menu, comment menu, bodymark menu and so on.
Use the trackball or the multifunctional knob to operate on the menu.
To show or hide the image menu, press <Menu> key on the control panel.
The menu area consists of menu title, menu items. As shown in figure below.
h Menu title
Displays the menu name.
h Tags
Menu title
Tags
Items
To Next Page
